HM Digital PSC-64D Mini Dual Display EC/TDS Monitor with 4-20mA Output

The HM Digital PSC-64D EC/TDS Monitor reads in an extended range to monitor TDS levels for high output commercial systems. If the TDS level rises above the user-set level, an alarm will sound and the unit will open or close a circuit via dry contacts to control a pump, solenoid valve or other external device.

Features:

• "Mini" Monitor. The HM Digital PSC-64D features a mini display which continuously monitors 2 lines while sending out a 4-20mA output.
• Extended Range for Monitoring EC/TDS. The HM Digital PSC-64D features an extended range to monitor both TDS and EC.
• Power Cord Included. The HM Digital PSC-64D features a power cord and other necessary parts that are included at no extra charge.

Specifications:

• Warranty: One year
• Temp Range: 33 - 167° F
• EC Measurement: 0-9999 µS / 0-20.00 mS
• TDS Measurement: 0 - 9999 ppm/ 0 - 10.0 ppt
• Settings: Controlled by on-screen up/down buttons

California residents Prop 65 Warning

WARNING!

This product contains materials known to the State of California to cause cancer and birth defects or other reproductive harm. www.p65warnings.ca.gov

Product Details
Accuracy	4-20mA ±0.2%
Features	2.3" LCD Display w/ backlight Auto Temp Control (1 - 65°C)
Max Temp (°F)	167
Min Temp (°F)	33
Power Source	AC 110V - 220V
Warranty & Certifications
Warranty	1 Year Manufacturer Warranty
Shipping Dimensions
Shipping Length	7.5 in.
Shipping Width	7 in.
Shipping Height	3 in.
Product Weight & Dimensions
Approx Depth	9.6"
Product Height	3 in.
Product Length	7.5 in.
Product Width	7 in.
Product Weight (lbs)	1.4
