20" BB Pentek S1-20BB Pleated Cellulose 20 mic Filter

S1 Series cartridges are manufactured from a pleated cellulose media and are designed for general water filtration purposes. The media is pleated around a polypropylene core for added strength and the ends are immersed in a thermo-setting vinyl plastisol. Embedding and sealing each end of the pleat in this fashion fuses the three components together forming a unified end cap and gasket.

Features:

• Economically priced
• Nominal 20-micron rating
• Reduces sand, sediment, silt, rust particles, and scale particles
• Pleated cellulose design maximizes dirt-holding capacity

The Pentek S1-20BB filter media is pleated around a polypropylene core for added strength and the ends are immersed in a thermo-setting vinyl plastisol. Embedding and sealing each end of the pleat in this fashion fuses the three components together forming a unitized end cap and gasket. An external netted sheath helps retain uniform pleat spacing in high flow and pulsating flow streams. The overlap seam is sonically welded to reduce bypass improving filtration efficiency.

Not Recommended for use with well water or other non-chlorinated sources. Also known as American Plumber® W20CLHD20, the Pentek S1-20BB is private labled for many other brands including: Ametek S1-20BB, Bruner S1-20BB, Keystone GC20-20, Kleen Plus S1-20BB, USFilter S1-20BB, Plymouth Products S1-20BB

Compatible with:

Cartridges for Heavy Duty Housings	W20CLHD20, 155305-51
Keystone	GPC20-20

California residents Prop 65 Warning

WARNING!

This product contains materials known to the State of California to cause cancer and birth defects or other reproductive harm. www.p65warnings.ca.gov

Product Details
Core Material	Polypropylene
Initial Pressure Drop	1.2 PSI Differential
Max Temp (°F)	145
Micron Rating (Nominal)	20 µm
Min Temp (°F)	40
Psid@Flow Rate	1.2 psid @ 10 GPM
Recommended Flow Rate	35 GPM
Surface Area	4280 Square Feet
Cap Material	Vinyl-Plastisol
Cartridge Style	Drop-in
Contaminants Reduced	Sediment/Dirt/Rust
Diameter	4-1/2"
End Cap Type	Double Open Ended (DOE)
Filter Construction	Pleated
Filter Type	Pleated
Flow Rate	35 GPM
Media Type	Resin Impregnated Cellulose
Micron Rating	20 µm
Origin	Mexico
Shipping Dimensions
Shipping Length	20 in.
Shipping Width	5 in.
Shipping Height	5 in.
Product Weight & Dimensions
Product Height	4.5
Product Length	19.75
Product Width	4.5
Product Weight (lbs)	1.75
