Shelco CSF-786 Single Cartridge Filter Housing with Ring Nut Closure

Shelco CSF-786 Series Stainless Steel Single Cartridge Filter Housings with Ring Nut Closure accept a single 9-3/4"-10" SOE cartridge and can have flow rates up to 7 gpm. The ring nut closure allows quick change-outs and secure sealing.

Specifications:

• Designed for high purity commercial or industrial filter applications
• Heavy-duty 316L stainless steel construction from maximum durability
• Electro-polished sump suitable for a wide range of process requirements
• Ring nut closure for quick, easy change-outs and secure sealing
• Accepts 9-3/4" to 10" SOE cartridges with 222 or 226 style connectors
• Flow rates up to 7 gallons per minute
• Inlet/Outlet: 3/4" FPT
• Includes mounting bracket kit and rod for opening and closing

Applications:

• Coolants
• Chemicals
• Electronics
• Food and Beverage
• Oil and Gas
• Paints, Inks, and Coatings
• Paper and Pulp
• Water

NOTE: Standard option CSF series housings are stocked and available for immediate shipment. Customized housings require 2-3 weeks to manufacture. For more information on returning customized items, see our Returns Policy.



California residents Prop 65 Warning

WARNING!

This product contains materials known to the State of California to cause cancer and birth defects or other reproductive harm. www.p65warnings.ca.gov

Product Details
Cap Color	Stainless Steel
Closure Type	Ring Nut
Drain Size	1/4" MPT
Gaskets	Buna-N (FDA grade)
Housing Material	316 Stainless Steel
Inlet Connection	3/4" FPT 1" FPT
Material Of Construction	316 Stainless Steel
Max Flow Rate	7 GPM
Max Pressure (Psi)	300
O-Rings	Buna-N
Outlet Connection	3/4" FPT,1" FPT
Size	3/4" 1"
Cap Material	316 Stainless Steel
Color / Finish	Stainless Steel
Connection Type	Female (FPT)
Origin	U.S.A.
Product Weight & Dimensions
Product Height	17-7/16"
Product Weight (lbs)	7
