Viqua VH410-F20 UV System Powered By Sterilight 18 gpm

The Viqua VH410-F20 Integrated Ultraviolet System is a great whole house filtration solution. The UV system integrates high-output, UV lamp technology with a high flow, sediment pre-filter, reducing installation steps! The VH410-F20 comes mounted on a reversible steel bracket, and is extremely compact are easy to install.

Features:

• Sterilum-HO UV lamps - High Output lamp technology allows you to treat high flow rates in a more compact space
• Integrated Sediment Filtration - A 5 micron pre-flter is included to the UV system, to ensure optimal performance of the UV Rays
• Safety Guaranteed - 4-log (99.99%) reduction of most bacteria, viruses and protozoan cysts at rated flow will keep your water safe to drink without adding chemicals
• Easily Programmable -A convenient controller allows constant output current and an universal power input
• Monitoring System -An audible alarm will sound if lamp needs replacement, or if the system has failed, ensuring safety for your home.
• Quality with Every Component -From the sealed case on the controller, which helps to prevent damage from accidental water intrusion, to the robust stainless steel chamber containing the UV lamp, Viqua Technology resonates quality all the way around.

  This system is compatible with the S410RL-HO Sterilight Lamp and the QSO-410 Quartz Sleeve. For any necessary system replacements, the UV Lamp/Quartz Sleeve Combo Kit for VH410-F20 includes:

• Sterilight Lamp (1): S410RL-HO
• Sterilight Quartz Sleeve (1): QSO-410
• Sterilight O-Rings (2): 410867

NOTE: 230V systems are shipped with 2-prong continental European (CEE-7/7) 2 pin with ground "Schuko" power cord.


California residents Prop 65 Warning

WARNING!

This product contains materials known to the State of California to cause cancer and birth defects or other reproductive harm. www.p65warnings.ca.gov

Product Details
Ambient Temperature Range	32-104 °F
Body Material	304 Stainless Steel
Features	Audible Lamp Failure Visual Power On Lamp Timer
Frequency Rate	50/60 Hz
Inlet Connection	3/4" FPT
Max Pressure (Psi)	125
Min Pressure (Psi)	5
Outlet Connection	3/4" FPT
Power	60 Watts
Size	3/4"
Connection Type	Female (FPT)
Contaminants Reduced	Bacteria Heavy Metals Cysts
Diameter	3-1/2"
Flow Rate	34 GPM (16mJ/cm2 Dose) 18 GPM (30mJ/cm2 Dose) 14 GPM (40mJ/cm2 Dose)
Type	Multi-Stage UV System
Voltage	120 V
Shipping Dimensions
Shipping Length	29.5 in.
Shipping Width	19.5 in.
Shipping Height	9.5 in.
Product Weight & Dimensions
Product Height	10.5 in.
Product Length	29.5 in.
Product Width	19.5 in.
Product Weight (lbs)	31
