Viqua VH200-F10 Cobalt Series UV System Powered By Sterilight 9 gpm

The Viqua VH200-F10 Cobalt Series Ultraviolet System incorporates high-output UV lamp technology coupled with the redesigned Cobalt series chamber, moving the inlet/outlet ports from an axial to S-shaped configuration making it more compact and easier to install. This system adds an integral 5 micron pre-filter to the VH200 system, that is mounted to a steel bracket.

Features:

• Sterilum-HO UV lamps - High Output lamp technology allows you to treat high flow rates in a more compact space
• Systems adds an integral 5 micron prefilter to the VH200 system
• 4-log (99.99%) reduction of most bacteria, viruses and protozoan cysts at rated flow will keep your water safe to drink without adding chemicals
• Cobalt ICE controller provides constant output current and a universal power input
• Controller alerts user with alarm if UV lamp fails
• Sealed case on the controller helps to prevent damage from accidental water intrusion
• Stainless steel reactor provides long life and eliminates the possibility of degradation from exposure to high intensity UV light
• Compact design reduces installation time and takes up less space
• Lamp can be changed without interruption of water flow

NOTE: This system is compatible with the S200RL-HO Sterilight Lamp and the QS-001 Quartz Sleeve. For any necessary system replacements, the UV Lamp/Quartz Sleeve Combo Kit for VH200-F10 includes:

• Sterilight Lamp (1): S200RL-HO
• Sterilight Quartz Sleeve (1): QS-001
• Sterilight O-Rings (2): 410867

230V systems are shipped with 2-prong continental European (CEE-7/7) 2 pin with ground "Schuko" power cord.


California residents Prop 65 Warning

WARNING!

This product contains materials known to the State of California to cause cancer and birth defects or other reproductive harm. www.p65warnings.ca.gov

Product Details
Ambient Temperature Range	32-104 °F
Body Material	304 Stainless Steel
Features	Audible Lamp Failure Visual Power On Lamp Timer Flow Restrictor
Frequency Rate	50/60 Hz
Inlet Connection	1" MPT 3/4" MPT
Max Pressure (Psi)	125
Min Pressure (Psi)	5
Outlet Connection	1" MPT 3/4" MPT
Power	35 Watts
Size	1" 3/4"
Connection Type	Male (MPT)
Contaminants Reduced	Bacteria Heavy Metals Cysts
Diameter	3-1/2"
Flow Rate	16 GPM (16mJ/cm2 Dose) 9 GPM (30mJ/cm2 Dose) 7 GPM (40mJ/cm2 Dose)
Type	Multi-Stage UV System
Voltage	120 V,230 V
Shipping Dimensions
Shipping Length	19.75 in.
Shipping Width	10 in.
Shipping Height	19.5 in.
Product Weight & Dimensions
Power Supply Dimensions	7.3"x3.2"x2-1/2"
Product Height	19.5 in.
Product Length	19.75 in.
Product Width	10 in.
Product Weight (lbs)	24
