Pelican PUV-8-P NSF Class B Ultraviolet Water System 8.9 gpm Compatible with Viqua D4-V Systems

The Pelican PUV-8-P NSF Class B Ultraviolet Water System is a whole house disinfection system that offers a 8.9 gpm flow rate and removes harmful bacteria, virus, and microorganisms. The Pelican PUV-8-P´s compact design, simple installation, and low cost of operation is ideal for small to medium size home. Drink confidently with Pelican´s quality and reliability from its high-output ultraviolet water purification system.

Specifications:

• Pelican controller with water-resistant case
• LED display showing lamp replacement reminder
• Indicator lights show the status of each system component
• Lamp timer reset button and mute button to silence audio alarm
• Stainless steel chamber with safety cap and special lamp plug
• Universal power input
• High-output UV lamp
• Three-year warranty
• Tested and certified by NSF International against NSF/ANSI Standard 55 for Disinfection Performance, Class B

NSF/ANSI Standard 55: Ultraviolet Microbiological Water Treatment Systems
This standard establishes requirements for point-of-use (POU) and point-of-entry (POE) non-public water supply (non-PWS) ultraviolet systems and includes two optional classifications. Class A systems (40mJ/cm2) are designed to disinfect and/or remove microorganisms from contaminated water, including bacteria and viruses, to a safe level. Class B systems (16mJ/cm2) are designed for supplemental bactericidal treatment of public drinking water or other drinking water, which has been deemed acceptable by a local health agency.
This system is compatible with the 602805 Trojan Lamp and the 602732 Quartz Sleeve. For any necessary system replacements, the UV Lamp/Quartz Sleeve Combo Kit for D4-V includes:

• Trojan Lamp (1): 602805
• Trojan Quartz Sleeve (1): 602732
• Trojan O-Rings (2): 2045

Replacement Parts:

• Trojan Lamp: 602805
• Trojan Quartz Sleeve: 602732
• Trojan O-Rings: 2045
• Trojan Ballast: 650713-007

California residents Prop 65 Warning

WARNING!

This product contains materials known to the State of California to cause cancer and birth defects or other reproductive harm. www.p65warnings.ca.gov

Product Details
Ambient Temperature Range	32-122 °F
Body Material	304 Stainless Steel
Inlet Connection	3/4" MPT
Max Pressure (Psi)	125
Min Pressure (Psi)	4
Outlet Connection	3/4" MPT
Power	50 Watts
Size	3/4"
Connection Type	Male (MPT)
Contaminants Reduced	Bacteria Heavy Metals Cysts
Diameter	4"
Flow Rate	8.9 GPM (16mJ/cm2 Dose)
Type	Single UV System
Voltage	120 V
Shipping Dimensions
Shipping Length	30 in.
Shipping Width	11 in.
Shipping Height	10 in.
Product Weight & Dimensions
Product Height	9.31
Product Length	30
Product Width	11
Product Weight (lbs)	19
