Luminor Blackcomb Vending UV System LBV-061 - 6 GPM LP System, 3/4" MNPT ports, 110V./50-60Hz

The Luminor Blackcomb Vending UV System LBV-061 is specifically designed for the microbiological protection of bottled water vending/dispensing machines, the Blackcomb vending system has all the features you need, and more, that place this design above all others.

Features:

• Two Piece Design. Allows for flexible mounting inside an enclosed vending machine.

• LED Indicators. A convenient visual sight port and a “power-on” LED indictor allow for easy confirmation of lamp operation, in addition to Green LED “lamp-on” indicator.

• Fully potted, electronic ballast. Comes equipped with an integral aluminum heat sink case that allows for cool operation inside these sometime harsh conditions.

• Easy-access industrial screw terminals. Provides simple connections for both power and volt free (dry) contacts allowing easy connection to the control board of the vending machine.

• Rugged 304 stainless steel, single-end reactors. Designed & manufactured to ASME pressure vessel standards allow for easy lamp change without the need to drain the reactor chamber as in competitive systems.

• Bayonet style lamp connector. Allows for easy lamp change without the need for additional tools.

• Low pressure (LP) coated UV lamps. Used offering a consistent output over their 9,000 hour rated life.

Specifications:

• Port Size: 3/4" MNPT
• Flow Rate*: 6 gpm
• Electrical: 110V / 50-60Hz
• Lamp Watts: 22
• Max Operating Pressure: 10 bar (150 psi)
• Operating Temperature Range: 36-104° F (2-40° C)

*Please Note: Flow Rate @ 30 mJ/cm² - Flow rate for a given dose is calculated based on system output at end of lamp life in water with 95% UVT

Luminor Blackcomb UV Systems

Model	LB4-061	LB4-101	LB4-201	LBH4-251 (High Output)	LBV-061 (Vending)
Flow Rate	5.8 gpm	11 gpm	21 gpm	25 gpm	6 gpm
Port Size	¾" MNPT	¾" MNPT	1" MNPT	1" MNPT	¾" MNPT
Electrical	110-230V	110-230V	110-230V	110-230V	110-230V
Lamp Watts	22	39	42	67	22
Max Operating Pressure	150 psi	150 psi	150 psi	150 psi	150 psi
Operating Temp. Range	36-104° F	36-104° F	36-104° F	36-104° F	36-104° F



California residents Prop 65 Warning

WARNING!

This product contains materials known to the State of California to cause cancer and birth defects or other reproductive harm. www.p65warnings.ca.gov

Product Details
Application	Coffee and Vending
Housing Material	304 Stainless Steel
Max Pressure (Psi)	150
Max Temp (°F)	104
Min Temp (°F)	36
Series	LBV
Change Frequency	9,000 Hours
Port Size	3/4" MNPT
Voltage	110-230V
Shipping Dimensions
Shipping Length	23 in.
Shipping Width	12 in.
Shipping Height	6 in.
Product Weight & Dimensions
Product Weight (lbs)	8.6875
