Sanitron S23A, 6 gpm, Ultraviolet Water Purifier

The Sanitron S23A Ultraviolet Water Purifier effectively treats water with higher concentration levels of turbidity, iron, manganese, and hardness.
Specifications:

• 2 to 416 gallons per minute, 120 to 25,000 GPH
• Potable and high purity water applications
• 304 or 316 stainless steel, electropolished and passivated
• Easy off retainer cap for effortless lamp change
• Drain plug for in place drainage of the purifier chamber
• Sight port to view germicidal lamp operation
• Removable flanged head for easy disassemble
• Patented dual action wiper mechanism for cleaning of the quartz sleeve
• Interchangeable chamber for 5,000 GPH and up
• Maximum recommended operating pressure for all purifiers is 100 p.s.i.
• Pressure drop at maximum recommended flow rate is less than 5 p.s.i.

Sanitron S23A Advantages:

• Effective - All micro-organisms are susceptible to Sanitron ultraviolet disinfection
• Economical - Hundreds of gallons are purified for each penny of operating cost
• Safe - No danger of overdosing; no addition of dangerous chemicals
• Fast - Water is ready for use as soon as it leaves the purifier, no further contact time required
• Easy - Simple installation and care. Compact units require minimum space.
• Automatic - Provides continuous or intermittent disinfection without special attention
• Chemical Free - No chlorine taste or corrosion problems
• Versatile - Capacities available from two to thousands of gallons per minute (g.p.m.)
• Stainless Steel Construction - 316 SS Electropolished
• Origin - Made in USA
• Warranty - 12 years UV chamber, 3 years Ballast, 1 year Lamp and Quartz Sleeve

Applications include home wells, farms, ranches, dairies, bottling plants, pharmaceutical and cosmetic industries, laboratories, hospital, electronic industries, food industry, hotels, aquarium and hatcheries, nurseries and pools, etc.


California residents Prop 65 Warning

WARNING!

This product contains materials known to the State of California to cause cancer and birth defects or other reproductive harm. www.p65warnings.ca.gov

Product Details
Body Material	316 Stainless Steel
Frequency Rate	50/60 Hz
Inlet Connection	3/4" MPT
Max Pressure (Psi)	100
Outlet Connection	3/4" MPT
Power	25 Watts
Size	3/4"
Connection Type	Male (MPT)
Contaminants Reduced	Bacteria Cysts Viruses
Diameter	4-5/16"
Flow Rate	6 GPM (30mJ/cm2 Dose)
Type	Single UV System
Voltage	120 V
Warranty & Certifications
Warranty	1 Year
Shipping Dimensions
Shipping Length	29 in.
Shipping Width	9 in.
Shipping Height	11 in.
Product Weight & Dimensions
Product Height	11 in.
Product Length	29 in.
Product Width	9 in.
Product Weight (lbs)	12.046875
