Viqua SV5Q-PA Silver Series NSF Class B UV System Powered by Sterilight 5.2 gpm

The Viqua SV5Q-PA Silver Series NSF Class B UV System is a reliable, economical and chemical-free way to safeguard drinking water in any residential application. This whole-house system is easy to maintain plus has a CSA and CE compliant power supply that is protected from damage and water intrusion. The Viqua SV5Q-PA Silver system has been designed and tested to ensure quality drinking water is at everyone´s fingertips.

Features:

• Class B Certified by NSF
• Equipped to inactivate chlorine-resistant parasites such as Cryptosporidium and Giardia, harmful bacteria like E.Coli and viruses not visible to the naked eye
• Specially designed and tested Sterilume™-EX lamps provide consistent and reliable ultraviolet output over the entire life of the lamp (9000 hours) to ensure continuous purification
• The system is easy to maintain and service
• The ultraviolet lamp can be changed without interrupting the water flow
• Built with a durable stainless steel chamber to prolong life and eliminate ultraviolet light degradation
• The controller visually displays the remaining lamp life and will go into alarm if the lamp fails. The D4-V+ systems are equipped with a UV sensor which provides a continuous readout of UV intensity


NSF/ANSI Standard 55: Ultraviolet Microbiological Water Treatment Systems This standard establishes requirements for point-of-use (POU) and point-of-entry (POE) non-public water supply (non-PWS) ultraviolet systems and includes two optional classifications.
Class A systems (40mJ/cm²) are designed to disinfect and/or remove microorganisms from contaminated water, including bacteria and viruses, to a safe level.
Class B systems (16mJ/cm²) are designed for supplemental bactericidal treatment of public drinking water or other drinking water, which has been deemed acceptable by a local health agency.


California residents Prop 65 Warning

WARNING!

This product contains materials known to the State of California to cause cancer and birth defects or other reproductive harm. www.p65warnings.ca.gov

Product Details
Ambient Temperature Range	36-104 °F
Body Material	304 Stainless Steel
Features	Audible Lamp Failure Visual Power On
Frequency Rate	50/60 Hz
Inlet Connection	3/4" MPT
Max Pressure (Psi)	125
Min Pressure (Psi)	5
Outlet Connection	3/4" MPT
Power	30 Watts
Size	3/4"
Connection Type	Male (MPT)
Contaminants Reduced	Bacteria Heavy Metals Cysts
Diameter	2-1/2"
Flow Rate	5.2 GPM (16mJ/cm2 Dose)
Type	Single UV System
Voltage	120 V
Warranty & Certifications
Warranty	7 yr for chamber, 1 yr for lamps and probes, 5 yr pro rated on all other components
Shipping Dimensions
Shipping Length	28 in.
Shipping Width	6 in.
Shipping Height	6 in.
Product Weight & Dimensions
Power Supply Dimensions	7.3"x3.2"x2-1/2"
Product Length	22"
Product Weight (lbs)	8.6
