Viqua Sterilight SSM-39 Silver Plus UV System 15.1 gpm

The Viqua Sterilight SSM-39 UV System provides point-of-use disinfection with a flow rate of 15.1 gpm. This modular system, incorporating Sterilight´s new Silver Plus controller, is ideal for small POU applications such as post filtration, or as a pre or post application on a residential RO System.

 Features:

• Silver Plus controller provides constant output current and a universal power input, and also displays % UV intensity, remaining lamp life, and total days of operation
• 254nm UV intensity monitor allows the SSM-39 to continuously monitor the system and warn you of any changes in water quality
• A powered solenoid output allows you to hook a normally closed solenoid valve (sold separately) directly into the controller.
• Sterilume™-EX coated low pressure germicidal UV lamps are used to provide an economical way of treating water requiring a 99.99% reduction in bacteria and viruses
• The SSM-39 is manufactured with a polished, 304 stainless steel, pressure rated tube and comes with ¼" MPT connections

This system is compatible with the S36RL Sterilight Lamp and the QS-012 Quartz Sleeve. For any necessary system replacements, the UV Lamp/Quartz Sleeve Combo Kit for SSM-39 includes:

• Sterilight Lamp (1): S36RL
• Sterilight Quartz Sleeve (1): QS-012
• Sterilight O-Rings (2): 410867

230V systems are shipped with 2-prong continental European (CEE-7/7) 2 pin with ground "Schuko" power cord.


California residents Prop 65 Warning

WARNING!

This product contains materials known to the State of California to cause cancer and birth defects or other reproductive harm. www.p65warnings.ca.gov

Product Details
Ambient Temperature Range	36-104 °F
Features	UV Intensity Monitor Audible Lamp Failure Visual Power On
Frequency Rate	50/60 Hz
Inlet Connection	3/4" FPT 1" MPT
Max Pressure (Psi)	125
Min Pressure (Psi)	5
Outlet Connection	3/4" FPT 1" MPT
Power	42 Watts
Size	3/4" 1"
Connection Type	Female (FPT) Male (MPT)
Diameter	3-1/2"
Flow Rate	15.1 GPM (30mJ/cm2 Dose)
Type	Single UV System
Voltage	120 V
Warranty & Certifications
Warranty	7 yr for chamber, 1 yr for lamps and probes, 5 yr pro rated on all other components
Product Weight & Dimensions
Power Supply Dimensions	11" x 4-1/2" x 2"
Product Length	37-1/2"
Product Weight (lbs)	15
