Viqua Sterilight SC2.5/2 Copper Series UV System 200-250V

The Viqua Sterilight SC2.5/2 Copper UV System 200-250V is specifically designed for point-of-use applications where microbiological control is required. The SC2.5/2 UV System controls bacteria, virus and protozoan cyst all in one complete design.

Specifications:

• 304 Stainless Steel Reactors
• Flow Rate: 2.5 gpm
• Dimensions: 16.5" x 2.5" Diameter
• Max Operating Pressure: 125 psi
• Inlet/Outlet Port Size: 1/2" MNPT/ 3/8" FNPT
• Volts: 200-250V/50-60Hz

This simple UV disinfection system has a minimal amount of parts with an integral electronic ballast with a visual alarm (LED). the Copper family of systems is ideal for small POU (point-of-use) applications. The ballast is built into the connector of the system. The UV reactor has an axial flow design and is manufactured in 304 stainless steel with combination ports of 3/8" FNPT and 1/2" MNPT connections.


California residents Prop 65 Warning

WARNING!

This product contains materials known to the State of California to cause cancer and birth defects or other reproductive harm. www.p65warnings.ca.gov

Product Details
Features	Visual Power On
Frequency Rate	50/60 Hz
Max Pressure (Psi)	125
Min Pressure (Psi)	5
Power	16 Watts
Diameter	2-1/2"
Flow Rate	2.5 GPM (30mJ/cm2 Dose)
Type	Single UV System
Voltage	220 V
Warranty & Certifications
Warranty	7 yr for chamber, 1 yr for lamps and probes, 2 yr pro rated on all other components
Product Weight & Dimensions
Product Length	16-1/2"
Product Weight (lbs)	4.6
