SHURflo 8005-243-256 Demand Pump 1.4 gpm 60 psi 12VDC

The SHURflo 8005-243-256 Demand Pump is ideal in applications that require high pressure and a flow rate of 1.4 GPM. The pump can be mounted in any position, is compact and is designed for long trouble-free life.

Specification:

• 1.4 GPM flow rate
• Pressure Switch (on at 45 psi, off at 60 psi)
• Max Inlet Pressure: 30 psi
• Can run dry without damage
• Self priming up 10 vertical feet
• 3/8" NPT female ports
• Santoprene diaphragm
• Built-in check valve
• UL Recognized Component
• NSF and CSA listed

Applications:

• Water delivery

California residents Prop 65 Warning

WARNING!

This product contains materials known to the State of California to cause cancer and birth defects or other reproductive harm. www.p65warnings.ca.gov

Product Details
Amps	2.1-4.7 Amps @ 0-60 PSI
Diaphragm Materials	Santoprene
Inlet Connection	3/8" FPT
Inlet Pressure	30 PSI
Outlet Connection	3/8" FPT
Power Source	None
Pump Max Flow Rate (Gpm)	1.4
Series	8000
Size	3/8"
Suction Lift	Self prime up to 10 ft
Voltage Type	DC
Wire Option	Bare Wire
Connection Type	Female (FPT)
Type	Diaphragm Pump
Voltage	12VDC
Shipping Dimensions
Shipping Length	14 in.
Shipping Width	6 in.
Shipping Height	6 in.
Product Weight & Dimensions
Product Height	4.5
Product Length	7.75
Product Width	4
Product Weight (lbs)	5
