Procon Pump NSF Brass 100 GPH 3/8" NPT - 150 psi PRV w/ 1143-2 Plastic Coupling (Clamp-on)

$70.99 $60.89

In Stock
  • Model: 112C100F11BB150-1421246726187

The Procon Pump NSF Brass 100 GPH 3/8" NPT - 150 psi PRV w/ 1143-2 Plastic Coupling (Clamp-on)  is a positive displacement pump. This Series 2 Procon pump is brass with a .188"...

Qty.
+ -
The Procon Pump NSF Brass 100 GPH 3/8" NPT - 150 psi PRV w/ 1143-2 Plastic Coupling (Clamp-on) is a positive displacement pump. This Series 2 Procon pump is brass with a .188" double flat drive and 1143-2 plastic coupling. The inlet and outlet ports are 3/8" NPT and the pump has a flow-rate of 100 gallons per hour. The seal configuration for the 112C100F11BB150 uses Nitrile Type 21 which will prevent leakage. The clockwise rotation of the pump operates at a nominal speed of 1725 rotations per minute. The Series 2 pumps are self-priming, so there is virtually no maintenance. The default pressure relief valve setting for this pump is 150 PSI. The 112C100F11BB150 pump is designed to be bolted on directly to the motor.

Features:
  • Leak-free.The seal configuration uses Nitrile Type 21, which will prevent leakage.
  • NSF Certified. NSF/Ansi Standard 169 for special purpose food equipment and devices.
  • Typical Applications. Beverage, espresso/coffee, cold carb circulation, reverse osmosis, beer chillers, pesticide systems, and solar applications.
  • Low Maintenance. The Series 2 pumps are self-priming, so there is virtually no maintenance.


Compatible with:
Procon102C100F11BB150

California residents Prop 65 Warning

warning symbol WARNING!

This product contains materials known to the State of California to cause cancer and birth defects or other reproductive harm. www.p65warnings.ca.gov



Product Details

Body Material

Brass

Capacity

15-125 GPH

Direction

Clockwise

Elastomer Type

Buna-N

Inlet Connection

3/8" MPT

Min Pressure (Psi)

100

Mounting Options

Clamp On

Outlet Connection

3/8" MPT

Power

1 hp

2 hp

Pump Max Flow Rate (Gpm)

100

Pump Max Pressure (Psi)

150

Series

2

Size

3/8"

Change Frequency

15-125 GPH

Connection Type

Male (MPT)

Type

Rotary Vane Pumps

Warranty & Certifications

Product Certification Standard

NSF/ANSI 169

Shipping Dimensions

Shipping Length

6 in.

Shipping Width

6 in.

Shipping Height

4 in.

Product Weight & Dimensions

Dimensions

Standard Clearance

Product Height

3.25

Product Length

4

Product Width

3.5

Product Weight (lbs)

3
