Procon Pump NSF Brass 100 GPH 3/8" NPT - 150 psi PRV w/ 1143-2 Plastic Coupling (Clamp-on)

The Procon Pump NSF Brass 100 GPH 3/8" NPT - 150 psi PRV w/ 1143-2 Plastic Coupling (Clamp-on) is a positive displacement pump. This Series 2 Procon pump is brass with a .188" double flat drive and 1143-2 plastic coupling. The inlet and outlet ports are 3/8" NPT and the pump has a flow-rate of 100 gallons per hour. The seal configuration for the 112C100F11BB150 uses Nitrile Type 21 which will prevent leakage. The clockwise rotation of the pump operates at a nominal speed of 1725 rotations per minute. The Series 2 pumps are self-priming, so there is virtually no maintenance. The default pressure relief valve setting for this pump is 150 PSI. The 112C100F11BB150 pump is designed to be bolted on directly to the motor.

Features:

• Leak-free.The seal configuration uses Nitrile Type 21, which will prevent leakage.
• NSF Certified. NSF/Ansi Standard 169 for special purpose food equipment and devices.
• Typical Applications. Beverage, espresso/coffee, cold carb circulation, reverse osmosis, beer chillers, pesticide systems, and solar applications.
• Low Maintenance. The Series 2 pumps are self-priming, so there is virtually no maintenance.

Compatible with:

Procon

102C100F11BB150

California residents Prop 65 Warning

WARNING!

This product contains materials known to the State of California to cause cancer and birth defects or other reproductive harm. www.p65warnings.ca.gov

Product Details
Body Material	Brass
Capacity	15-125 GPH
Direction	Clockwise
Elastomer Type	Buna-N
Inlet Connection	3/8" MPT
Min Pressure (Psi)	100
Mounting Options	Clamp On
Outlet Connection	3/8" MPT
Power	1 hp 2 hp
Pump Max Flow Rate (Gpm)	100
Pump Max Pressure (Psi)	150
Series	2
Size	3/8"
Change Frequency	15-125 GPH
Connection Type	Male (MPT)
Type	Rotary Vane Pumps
Warranty & Certifications
Product Certification Standard	NSF/ANSI 169
Shipping Dimensions
Shipping Length	6 in.
Shipping Width	6 in.
Shipping Height	4 in.
Product Weight & Dimensions
Dimensions	Standard Clearance
Product Height	3.25
Product Length	4
Product Width	3.5
Product Weight (lbs)	3
